Anti-Lock Brakes for 2024 Volkswagen Golf R
No.
Part # / Description / Price
Price
1
ABS Pump Assembly
Volkswagen
Volkswagen Notes: PARTS: Part number and pricing are for estimating purposes only. Contact local dealer for specifc part number and pricing.
Description: From 06/19/2023. GTI. Golf R.
4
Control Module Volkswagen
Volkswagen Notes: PARTS: Part included with ABS pump assembly. Part number and pricing are for estimating purposes only. Contact local dealer for specific part number and pricing.
Description: From 06/19/2023. GTI. Golf R.
No.
Part # / Description / Price
Price
1
Hub & Bearing Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part has related component that cannot be reused/reinstalled; mount bolt.
Description: Golf R.
MSRP $302.08
$199.38
MSRP $302.08
$199.38
2
Axle Bolt Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part cannot be reused/reinstalled.
Description: To 06/11/2018. Awd. Without r.
MSRP $3.72
$2.23
MSRP $3.72
$2.23
3
MSRP $2.58
$1.55
4
MSRP $481.24
$317.61
4
MSRP $307.99
$203.27
4
MSRP $551.24
$360.51
4
MSRP $367.49
$242.54
4
Disc Brake Caliper Volkswagen
Volkswagen Positions: Right
Description: Blue. Golf R. Right.
MSRP $498.74
$329.16
MSRP $498.74
$329.16
5
Brake Bleeder Screw Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with caliper.
Description: Brazil Built Vehicle. 10 x 1mm. 272mm Brake Rotor. 288mm Brake Rotors. 288 x 25mm Brakes. 10 x 1mm. Vendor:bosch. With r. 312mm Brake Rotors. 18" Wheels. From Chassis/VIN 70V047441. To Chassis/VIN 1C-7-512 080. Vented Brake Rotors.
MSRP $29.38
$17.63
MSRP $29.38
$17.63
6
Bleeder Valve Dust Cap Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with caliper.
MSRP $15.10
$9.06
MSRP $15.10
$9.06
8
MSRP $115.37
$83.99
9
MSRP $214.98
$141.89
9
MSRP $214.98
$141.89
9
MSRP $198.31
$130.89
10
MSRP $42.61
$24.51
12
Rotor Front Volkswagen
Volkswagen Positions: Left
Description: 310mm. 310mm Dia. A single Disc brake Rotor. All Wheel Drive 310X22mm. From 10/10/2016. Front Wheel Drive 310X22mm. Part has related component that cannot be reused/ reinstalled; screw. Performance Package. To 10/09/2016.
Fits Arteon, CC, e-Golf, Golf, G ...
MSRP $113.70
$82.78
MSRP $113.70
$82.78
14
Splash Shield Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part has related component that cannot be reused/reinstalled; mount bolt.
Description: Tiguan. Left. Arteon. All wheel drive, 310x22mm. Golf R. Fwd. With awd, from 12/05/2016. All wheel drive, 300x12mm.
MSRP $46.62
$26.81
MSRP $46.62
$26.81
14
Splash Shield Volkswagen
Volkswagen Positions: Right
Notes: PARTS: Part has related component that cannot be reused/reinstalled; mount bolt.
Description: Tiguan. Right. All wheel drive, 310x22mm. Arteon. With awd, from 12/05/2016. Golf R. Fwd. With awd, to 12/04/2016.
MSRP $54.32
$31.23
MSRP $54.32
$31.23
16
Brake Hose Volkswagen
Volkswagen Positions: Left
Description: Arteon. With 4 link suspension. Front wheel drive, 310x22mm. Without awd, with e-Golf. GTI. Fwd. Taos. Golf R. All wheel drive, 300x12mm. Front wheel drive, 300x12mm.
MSRP $89.98
$60.47
MSRP $89.98
$60.47
17
MSRP $7.97
$4.79
18
ABS Sensor Volkswagen
Volkswagen Positions: Right
Description: With awd. All wheel drive, 310x22mm.
MSRP $158.31
$106.39
MSRP $158.31
$106.39
18
ABS Sensor Volkswagen
Volkswagen Positions: Left
Description: With awd. All wheel drive, 310x22mm.
MSRP $169.98
$112.19
MSRP $169.98
$112.19
19
ABS Sensor Wire Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Order by application
Description: With adaptive chassis.
MSRP $173.84
$124.29
MSRP $173.84
$124.29
19
ABS Sensor Wire Volkswagen
Volkswagen Positions: Right
Notes: PARTS: Order by application
Description: With adaptive chassis.
20
Parking Brake Actuator Volkswagen
Volkswagen Positions: Left
Description: GTI. Left. Golf R. Electric Motor.
MSRP $371.81
$245.40
MSRP $371.81
$245.40
20
Parking Brake Actuator Volkswagen
Volkswagen Positions: Right
Description: GTI. Right. Golf R. Electric Motor.
MSRP $574.98
$376.04
MSRP $574.98
$376.04
21
Motor Hardware Kit Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with motor.
Description: All wheel drive, 310x22mm. Front wheel drive, 310x22mm. With 4 link suspension. Without awd, with e-Golf. Fwd.
MSRP $8.32
$4.99
MSRP $8.32
$4.99
No.
Part # / Description / Price
Price
1
Bearing Assembly Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part has related components that cannot be reused/reinstalled; mount bolt.
Description: All wheel drive, 310x22mm. From 02/01/2021. Golf R. Arteon. Awd.
MSRP $314.99
$207.89
MSRP $314.99
$207.89
2
Hub & Bearing Mount Bolt Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part cannot be reused/reinstalled.
MSRP $2.58
$1.55
MSRP $2.58
$1.55
3
Axle Bolt Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part cannot be reused/reinstalled.
Description: To 06/11/2018. Awd. Without r.
MSRP $3.72
$2.23
MSRP $3.72
$2.23
4
MSRP $398.11
$262.76
4
MSRP $603.74
$394.84
5
Disc Brake Caliper Bracket Mounting Bolt Volkswagen
Volkswagen Positions: Left
Description: Rear wheel drive. All wheel drive. 312x25 rotor. Without performance brakes. With gli. From 09/28/2020. With r.
MSRP $14.88
$8.93
MSRP $14.88
$8.93
6
Bleeder Valve Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with caliper.
Description: Without link suspension. Without awd, without e-Golf. Without performance brakes. 2021-22. 312x25 mm. Fwd. Without r, to 10/2009. Sedan from 1/05, wagon 2009 only, with 260mm rotor. From Chassis/VIN 1C-7-512 081.
MSRP $31.98
$19.19
MSRP $31.98
$19.19
7
Bleeder Valve Dust Cap Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with caliper.
MSRP $15.10
$9.06
MSRP $15.10
$9.06
8
Caliper Mount Volkswagen
Volkswagen Positions: Left
Description: Blue. Incl.Disc Brake Caliper Guide Pin.
MSRP $354.15
$233.74
MSRP $354.15
$233.74
9
Disc Brake Caliper Pin Boot Volkswagen
Volkswagen Positions: Left
Description: All Required.
MSRP $43.03
$24.75
MSRP $43.03
$24.75
10
Disc Brake Caliper Anchor Plate Bolt Volkswagen
Volkswagen Positions: Left
Notes: PARTS: Part included with bushing kit.
Description: With r. 340x30 mm.
MSRP $7.50
$4.50
MSRP $7.50
$4.50
11
MSRP $190.75
$136.39
12
MSRP $214.63
$153.46
16
MSRP $124.98
$83.99
17
MSRP $7.97
$4.79
18
Brake Hose Holder Volkswagen
Volkswagen Positions: Left
Description: Without gli. 288x25 rotor. 340x30 mm, lower. With gli, lower. With performance brakes. With r.
MSRP $14.51
$8.70
MSRP $14.51
$8.70
18
Brake Hose Holder Volkswagen
Volkswagen Positions: Right
Description: Without gli. 312x25 rotor. 340x30 mm, lower. With gli, lower. 288x25 rotor. With performance brakes. 312x25 mm, lower. With r.
MSRP $15.94
$9.56
MSRP $15.94
$9.56
19
Brake Hose Bracket Volkswagen
Volkswagen Positions: Left
Description: Without gli. 288x25 rotor. 340x30 mm, upper. With gli, upper. With performance brakes. 312x25 mm, upper. With r.
MSRP $12.28
$7.37
MSRP $12.28
$7.37
19
Brake Hose Bracket Volkswagen
Volkswagen Positions: Right
Description: Without gli. 288x25 rotor. 340x30 mm, upper. With gli, upper. With performance brakes. With r.
MSRP $12.28
$7.37
MSRP $12.28
$7.37
21
ABS Sensor Wire Volkswagen
Volkswagen Positions: Left
Description: With ft matrix lamps, with adapt chassis.
MSRP $155.37
$111.09
MSRP $155.37
$111.09
21
ABS Sensor Wire Volkswagen
Volkswagen Positions: Right
Description: With ft matrix lamps, with adapt chassis.
MSRP $215.37
$153.99
MSRP $215.37
$153.99
